Access to the Relianoid web GUI #

If you’ve successfully installed or deployed Relianoid 6.2, you will be able to access the load balancer via the web through the default HTTPS port 444:

https://<LB_IP>:444

And after accepting the secure certificate, you’ll be able to access the login panel. Please, do not forget to change the default root password.

Default user and password #

The default user and password to access Relianoid Load Balancer are:

user: root
password: admin

Note: If the load balancer has been installed (not deployed from a virtual template), then the password will be the one that you set during the installation process. Please, do not forget to change the default system password via System >> Users.

Main panel #

On logging In, you’ll find a menu that expands or collapses when clicked in the top left section of the web panel. At the top right section, you will see the user or node name. When you click the root drop-down icon, you will see a menu with the user settings, a button for requesting help, and a logout option. The notification icon displays the number of packages that require updates. Finally, the menu item of the cluster status and the load balancer appliance hostname.
