SKU: TRANSCEIVER40GB

40BASE-SR4 850NM Multimode QSFP+ Transceiver

40GB QSFP+ transceiver modules are designed for use in 40 Gigabit per second links over multimode fiber. They are compliant with the QSFP+ MSA1,2 and IEEE 802.3ba 40GBASE-SR43 and breakout to 4 10GBASE-SR. Digital diagnostics functions are available via an I2C interface, including Tx and Rx power monitoring. The transceiver is compliant per the RoHS Directive 2011/65/EU4 . See Finisar Application Note AN-20385 for more details.

265.00$
FOX v.1.4.2.1
  • Four-channel full-duplex transceiver module
  • Reliable VCSEL array technology
  • Built-in digital diagnostic functions, including optical power monitoring
  • Commercial operating case temperature range: 0ºC to 70ºC
  • Single 1×12 MPO receptacle
  • RoHS-6 Compliant
  • Hot Pluggable QSFP+ form factor
  • Maximum link length of 100m on OM3 Multimode Fiber (MMF) and 150m on OM4 MMF
  • Multirate capability: 1.06Gb/s to 10.5Gb/s per channel
  • Unretimed XLPPI electrical interface
  • Max power dissipation <1W
  • 40GBASE-SR4 40G Ethernet
  • Breakout to 4 x 10GBASE-SR Ethernet
  • Proprietary interconnections
